1.5 MP resolution2.100M IR Distance , Smart Dual Light (4Far+4Near+2White)3.Powerful 30X optical zoom4.Support ONVIF5.Deep perimeter: supports cross-border detection, enter area, leave area, area intrusion 4 kinds of arming modes6.Video Analysis Light-Adjustment Technology7.IP 66 all-environments protection8.Support POE
-
Model No
PB50-S30X
Camera Parameters
Image Sensor
1/2.8" Progressive Scan CMOS
Resolution
5MP(2592X1944)
Mini Illumination
0.05 Lux (Colour) (F1.6,AGC ON), 0.01 Lux (B/W) (F1.6,AGC ON)
Lens
f= 4.5 ~ 135 mm
IRIS
F1.5 ~F22
Angle of View
57.6°(wide) ~ 2.5°(tele)
Min Object Distance
10mm~1500mm
Optical Zoom
30X
Electronic Shutter
1/25~1/30,000s
Day/Night
ICR (Auto/color/black)
Focus
Auto/Manual
AGC
Auto/Manual
BLC
Auto/Manual
White balance
Auto/Manual
SNR
>52dB
WDR
Support
Mirror Image
Level, Tilt, Centre
Noise Reduction
3D
Network Parameters
CPU
SSC377D
Video Coding
H.264/H.265
Dual-stream
Support
Image Resolution
Main stream：25@FPS(2592×1944,2560×1440,2304×1296,1920X1080,1280X720)
Sub stream:D1,VGA,640×360Audio Coding
G.711/G.711A/AAC
ONVIF Protocol
Support
Network Protocol
TCP/IP、HTTP、DHCP、DNS、RTP、RTSP、NTP、UPnP
Port
1channel network port，1channel power supply input
Dome Parameter
IR Distance
100m, Support Smart Dual Light(4Far + 4Near + 2White)
Pan Range
360°
Tile Range
-15°~90°
Manual Speed
Horizontal: 0°/s - 100°/s,Vertical: 0°/s - 80°/s
Preset Speed
Pan: 100°/s，Tile: 80°/s
Preset
256
Auto Cruising
1 groups（32 Preset/group）
Auto Scan
1 groups（setup left and right boundary）
Pattern Scanning
1 groups
Bracket
Wall mount
Power Supply
DC12V±10%
Power Consumption
≤18W
Working Temp
-35℃~+60℃
Working Humidity
≤95%
Protection Level
IP66
Package Size
250*245*160mm
Weight
2kg
-
